| 項 目 | 仕 様 | |
|---|---|---|
| 3G Module | Quectel UC20G | |
| Frequency Range | UMTS / HSPA+: 800 / 850 / 900 / 1900 / 2100MHz GSM / GPRS / EDGE: 850 / 900 / 1800 / 1900MHz | |
| CPU | Ralink RT3352 | |
| Operating System | Embedded Linux | |
| Flash Memory | 16MB (Max 8MB is reserved for customer application S/W) | |
| RAM | 64MB | |
| Interface | LAN | 100BASE-T x1 RJ-45 female socket |
| UART Lite | Serial port | |
| RS232/422/485 Selectable | D-sub 9 male | |
| Digital I/O | ||
| USB A | USB 2.0 (DC 5V, 500mA Power Supply available) | |
| WLAN | IEEE 802.11b/g/n (Option) | |
| WLAN DATE RATE | 802.11n (150Mbps) / 802.11g (up to 54Mbps) / 802.11b (up to 11Mbps) (Option) | |
| Antenna | External SMA Type Antenna x 1 | |
| LED | PWR/WLAN/Module State/RSSI | |
| Key | ON/OFF Switch. Reset Key | |
| Battery | Li-Ion (1,100mA) for back-Up (Option) | |
| Size | About 75mm x 105mm x 28mm | |
| Weight | 150g | |
